Krelus infrared heaters are well-suited for drying applications since water absorbs IR radiation in the medium-wave infrared range excellently. The KRELUS MINI heaters can be perfectly combined to make heater fields in various sizes. Due to the grid dimension, both models can be used in the same field and can be individually controlled in separate heating zones as the needed. They can also be used individually.
Technical Data
Metric
Imperial
Article
117.131
Voltage
230 V
Current
8.7 A
Frequency
50/60 Hz
Power
2000 W
Power density
32 kW/m²
Max. ambient temperature
500 °C
Pyrometer hole position
Standard
Length
496 mm
Width
123 mm
Height
65 mm
Weight
2.7 kg
Approvals
CE
Protection class (IEC 60529)
IP20
Protection class
I
Highlights
Best heat absorption
Medium-wave IR radiation for optimum absorption
Temperature infinitely variable
Power density up to 50 kW/m² respectively 32 W/in²
