The LHS 410 P (as well as the LHS 210 P) is the first compressed air heater from Leister designed for an operating pressure of up to 6 bar. Its housing is made of pressure-resistant material. The LHS 410 P can be operated directly with compressed air and requires no additional blower. Thanks to its compact design, it is ideal for integration into industrial systems, such as tube production.
Technical Data
Metric
Imperial
Phases
1x
Voltage
230 - 400 V
Current
14 - 19.5 A
Power
3600 - 5500 W
Max. air outlet temperature
650 °C
Min. airflow
Required minimum air volume at 100% heating power and an air inlet temperature of 20°C / 68°F
280 - 420 l/min
Max. air inlet temperature
100 °C
Max. ambient temperature
65 °C
Overheating protection
No
Max. inlet pressure
600 kPa
Display
No
Length
178 mm
Width
80.5 mm
Height
186 mm
Weight
2.22 kg
Approvals
CE
Protection class
I
Highlights
Robust and compressed air operated
Sophisticated and compact
Reinforced housing
The reinforced housing offers more safety and allows operation with compressed air. In addition, the air heater requires little space.
resistant
Suitable for compressed air operation
The LHS 410 P uses compressed air up to 6 bar operating pressure. An additional blower is not required, saving space in industrial systems.
versatile
Adapter flexibly selectable
The LHS 410 P can be equipped with various adapters. Compressed air or blower adapters are possible at the air inlet and double flange, tubefilling, nozzle or thermocouple adapters at the air outlet.
